● Capable of supplying 2-3 fixtures
● 3-chamber diaphragm pump
● On-demand long life pressure switch
● Adjustable pressure switch
● Self-priming
● Capable of being run dry
● Rubber mounting base for vibration & noise reduction
● Industry standard mount pattern
● Quiet operation
● Thermal overload protected with Automatic restart feature
● Marine grade blocked wiring
● 60°C (140°F) temperature limit
● Shut-off Pressure 45 PSI: 35 PSI ±5 PSI (±0.3 bar)
● Valves: EPDM
● Diaphragm: Santoprene
● Inlet/Outlet Ports: 1/2″-14 MNPT
● Leads: 16AWG x 11.4cm
● Weight: 1.8kg
● Meets or exceeds RoHS, SGS and ISO standards
Art No. Open Flow GPM / LPM Shut-off Pressure PSI / BAR Volts Max Draw Control Type Priming Capabilities
DP103004533 3.0 / 11.3 45 / 3. 12 V 6.74 A Switch 1.8 m / 6′
